Talbert 60CC/55SA-LD low boy trailer allows operation of the third axle only, or a combination of third and fourth axles. The 60CC/55SA-LD also features an 18-inch deck height and 6-inch ground clearance.
The base model of the 60CC/55SA-LD features a 108-inch swing radius, 26-foot deck length, and 8-foot-6-inch deck width. Additional customization is possible, including a 24-inch flip gooseneck extension that increases swing radius to 132 inches and allows greater load transfer capabilities.
The trailer offers a four-axle, close-coupled configuration, and provides a 55-ton capacity in 10 feet and 60 tons in half the deck length. It is also rated for 55 tons in half the deck length with a 132-inch swing radius and 3+1 configuration with the E1Nitro axle extension system. This system uses a combination of hydraulic fluid and nitrogen to equalize axle pressures, providing proportionate weight distribution of each axle grouping to optimize the range of suspension movement and minimize stress for a smoother ride.
